Automatic nailing machine electronic semi-automatic riveting machine CNC components helmet semi hollow rivet machine riveting keyhole machine Add time：2020-08-15
Product details
1、 Operation preparation and operation
1. Check whether the machine is stable.
2. Whether the power socket is firmly plugged in.
3. Check the rocker arm, flywheel and guide rail for foreign matter.
4. Turn on the power and test the pedal. If the motor runs normally, the preparation is finished.
5. Place the required riveting parts holes on the floating center pin for riveting.
6. Step down the foot pedal to rivet the rivet into the hole position of the parts, and then return to the original top dead center to complete the work cycle.
2、 Maintenance of riveting machine
1. The power must be turned off and the cleaning should be carried out from the inside out and from the top to the bottom.
2. Cleaning of rivet storage tank: remove the rivet storage tank and take out the surplus rivet to prevent subsequent production
If the remaining rivets are mixed up and cause damage to riveting products, clean them with cotton cloth and install them back after cleaning.
3. Clean the guide rail, pull the guide rail block to make the remaining rivets in the guide rail flow into the guide groove of the clamp mouth, and press down
The movable frame takes out the remaining rivets from the clamp mouth, and wipes the guide rail, clamp mouth and upper mold rod with cotton cloth.
4. Clean the funnel, screw off the fixed nut of the funnel, take down the pressure spring, take down the funnel, and use a slotted screwdriver
Clean the surplus rivets in the funnel, wipe them with cotton cloth, and then replace them according to the disassembly sequence.
5. Clean the lower die base, remove the protective cloth cover of the lower die base, and clean the remaining washer on the floating center pin.
6. Clean the periphery, clean the dirty surface of the machine. If the machine can not be wiped clean or there is tape, banana can be used
Wipe with water.
7. Clean the rocker arm and motor, clean the motor cover, and then clean the belt pulley and belt guard, such as
If too much dust is not cleaned in time, the motor will be hot and cause damage to the motor.
8. After cleaning, plug in the power supply, turn on the power, turn on the equipment, and check whether the parts are running
If it is normal, it can be put into production.
